Quam ad test fibra opticus panni rudis funibus?

Fibra opticus lacus funis Testing practical Guide

I. Basic continuitatem test
Tool: Rubrum lux Pen (Visual Cless Locator)
Procedure: Connect unum finem panni rudis in rubrum lux stylo et uisum observe lucem output ab alio finis (non spectare directe in fibra portum).
Pass: Red lumen est aequaliter traducitur (nec obscura maculis aut flickering).
Deficient: A splendida Rubrum macula est visibilis ad breakpoint (locus fibra core confractus).

II. Endface contamination deprehensio
Tool: fibra opticum microscopium (200x magnificatio vel altius)
Procedure: Remove in patch spinalis pulveris cap et directe observe ad iungo endma (Power off primo).
Pass: et Ceramic sleeve est mundus, liberum de scalpit et oleum maculas.
Defectum:
Pulveris / fingerprints: Blocking optical Semita (requirit specialem Purgato calamum).
Fractorum / eu: statim abiicias (irreparabilis).

III. Critical damnum test
Tool: Optica potentia meter firmum lux fontem
Procedure: Coniungere lux fons ad unum finem panni rudis et emittunt referat lucem (E.G., 1310nm). Coniungere in potestate meter ad alterum finem et legit damnum valorem (DB).
Pass:
Multimode panni rudis funis: ≤0.5db (in C metris).
Single-modus patch funem: ≤0.3DB (in I kilometer).
Defectum: Loss >1dB (possible: excessive bending/endface degradation).

IV. Polarity verificationem (Duplex / MPO Draconis)
Duplex panni rudis funis:
Modum: Iungo a rubrum laser monstratorem ad TX finem; Rx finem emit lux (crossover).
MPO Draconis funis:
Mors: MPO Polarity Tester
Determinatio: Type A-B (Right-per) vel Typus A-C (Crossover) oportet inserere machinam interface.

V. Aequaliter VALIGNUM Test
Sem, periculo flexuram / trahens in lacus spinalis post deployment
Procedure:
4CM diameter cylindrici triplici cylindro lacus involvent.
Monitor optical potentia fluctuatio in ipsa tempore per test.
Pass: Fluctuation ≤0.2DB (flectere-insensitive panni rudis funis). Defectum: Power Iacta> 1DB (Jacket aut fibra core laedantur).

VI. Environment Testing
Temperatus adductius test (tantum requiritur ad velit patch funibus):
Fridge (-20 ° F) → locus temperatus → clibano (LX c) exolvuntur III temporibus.
Tempus: Damnum Mutare <0,1DB.
Waterproof test (IP67-rated panni rudis funibus):
Immering in Iungo in aqua ad XXX minuta, extergimus aridam, et mensura velit resistentia (> 1000mω).
